Kinetico Drinking Water Filter
with MACguard
®
Undersink Models 7000 and 7500
Installation Instructions
Rev.: 01/2011 Kinetico Incorporated ◆ Corporate Headquarters ◆ Newbury, Ohio 44065 ◆ (440) 564-9111 Product No. 9383H
4
4. Remove the plastic wrapping from the filter cartridge. Remove the small plastic cap from the top of the filter cartridge
(See Figure 5). Install the cartridge into the filter head/bracket assembly by firmly inserting it and rotating it
counterclockwise until it stops.
Figure 5. Filter Cartridge Cap Removal
5. Determine the desired location for the filter system. It should be easily accessible for cartridge replacement. Be sure
to leave adequate clearance under the filter to facilitate cartridge changes and allow for easy viewing of the
PureMometer filter life indicator.
NOTE: Do not install in direct sunlight. The screws provided are for use with structurally sound wood
surfaces. You may need other mounting hardware if you are mounting on other surfaces.
Warning
Do not use the fittings provided on chrome tubing. If your plumbing type requires
different fittings than those provided, you may obtain them at a local hardware
store or home improvement center.
6. Using the bracket mounting screws, mount the filter system in the location you have chosen (See Figure 6).
7. Locate the cold water line you will tap into to supply water to the filter system. DO NOT USE THE HOT WATER LINE.
Turn off the water to the cold water feed line. Plumb in a hookup with the ability to connect to ¼” tubing (See Figure
77). A tee fitting is provided to accommodate most installations.
NOTE
: The installation must comply with state and local codes and regulations.
SPECIFICATIONS:
Service Flow Rate: Model 7000: 3.75 Lpm (1.0 gpm)
Model 7500: 2.84 Lpm (0.75 gpm)
Min./Max. Operating Pressure: 137.9 - 827.4 kPa (20 - 120 psi)
Min./Max. Operating Temperature: 2 - 38°C (35 - 100°F)
Capacity: 1,892 L (500 gal)
