1014336 Issue 01 BioTec+ Control Panel User Manual
5
4.3 Pressure Sensor
The control panel is equipped with an analogue 0-500mBar pressure sensor which measures the pressure
inside the valve chamber. Thus, it monitors the pressure at all valves. The pressure monitoring can be used for:
• Blower monitoring (Low pressure alarm)
• Valve monitoring (High pressure alarm)
• Water level (High level alarm)
• Deactivation of Clearwater Airlift
5. General Operaon
The control panel is operated by pushing the ↑, ↓ and OK buons. The default login for the Service Menu is
1111.
5.1 System Operaon
With the system is installed, the only input required on the panel, is to set the me. Once set, the panel will
synchronize the cycles from midnight.
The system runs two cycles per day. Each cycle = 9hours aeraon/1hour selement/1hour clearwater
removal/1hour denitricaon. Note during aeraon the blower cycles on and o.
The airli pump out (gravity) uses pressure dierenal seen by the panel to acvate high level and low level to
switch o aer pumping out.
The submersible pump out (IPS) is controlled by the panel, the oat on the pump prevents dry running. Note
during holiday periods, the system will run as normal, but pump out will not operate as the pump oat will be
in the down posion.
Should the system overll, the panel will acvate 1hour seling mode, aer which the system will pump out.
