Kingtex NT67 User Manual

12
5. 縫針
5-1 縫針系統
NT67 使用的縫針為 FL*118GCS/Organ 與 FLG-1/Organ，依照裁片的性質及厚度，
選擇適當的縫針。
5. Proper operation
5-1 Needle system
Sewing needle:
Organ FL × 118GCS
Retainer needle:
Organ FLG-1 FLG-8 (with scarf)
縫針/控制用針 號數與粗細對照表
Select the proper retainer needle in size depending on thickness and
type of the material.
5-2 縫針安裝
注意，在安裝縫針時，一定要切斷電源，
同時確認馬達已經完成停止。
縫針的針柄上刻有兩個平槽，安裝縫針時，必須確認
針柄推進到定位孔底，
平槽對正螺絲孔後再鎖緊固定螺絲。控制用針安置在
最右邊。
5-2 Needle change
Before installing the needles, ALWAYS turn the motor
switch OFF and check the motor had already stopped
completely.
The shank of the needle includes the flat part.
Insert needle into the inmost point of the needle
clamp and tighten them with the screws.
Replacing needle
1. Raise the needles at the highest point.
2. Loosen screws and remove the old needle(s).
3. The flat part face front, insert new needle into
the needle clamp as far as they go.
Tighten the screw securely.
Japanese(日本)
standard
8
9
10
11
12
_
14
Metric(公制)
standard
60
65
70
75
80
_
90
