安裝離合馬達及三角皮帶 How to select motor pulley and V-Belt
 請使用 3 相 2 極 400W(1/2HP)離合馬達
 請使用 M 類的 V 形三角皮帶
 市購的三角皮帶輪級距為 5mm，附表為計算出近似的轉速，配合適當的
三角皮帶號數
shows the outside diameter of the motor pulley, rpm of the machine,
and size of the belt when using the clutch motor of 3-phase, 2-pole,
400W(1/2HP).
The outside diameter on the table shows the nearest size to the calculated
values based On the commercial pulleys at intervals of 5 mm.
皮帶輪，轉速與皮帶號數 Motor puller and V-belt
皮帶輪直徑
OutsideDiameter
Of pulley (mm)
縫機轉速
rpm of machine
皮帶號數
Clutch motor V-Belt size
50Hz
60Hz
TTS11
HTS21
50
2650
M31
M57
55
2900
M31
M57
60
2650
3200
M32
M58
65
2900
3450
M32
M58
70
3100
3700
M32
M58
75
3300
M33
M59
80
3500
M33
M59
85
3750
M33
M59
