安裝離合馬達與掛載三角皮帶
踩下腳踏板啟動離合器馬達時，馬達上的皮帶輪會向右移動。
安裝離合馬達時要注意中心線的變化。
中心線偏差會造成皮帶過度的磨耗及噪音。
Hanging belt
Use the M-type of V-belt.
To install the clutch motor, align the center of the machine
pulley with that of the motor pulley when the motor pulley shifts
to the left with the pedal toeing down.
Hang the belt on the machine pulley, and then on the motor pulley while
rotating the machine pulley.
Adjust the belt tension so that the belt has 10 – 20 mm slack when its center
is pushed with 1kg of strength Fix the motor with the adjusting bar.
