Kioti LX500L User Manual

5
-
13
OPERATION
5
(1) Headlamp Switch
(A) Tail Lamp (B) "OFF"
(C) "ON" (Low Beam) (D) "ON" (High Beam)
S76o517a
(2) Headlamp Switch
• A: Headlamp-tail lamp (ON)
• B: OFF
• C: Headlamp-low beam (ON)
• D: Headlamp-high beam (ON)
(3) Hazard Warning Flasher Switch
The indicators on the instrument panel
ashwhenthehazardwarningasher
switch is "ON".
Turn the switch to "OFF" position to
turn off the hazard warning asher
switch.
4. CHECKING THE BRAKE PEDAL
(1) Brake Pedal (LH, RH)
(1) Brake Pedal (LH) (2) Brake Pedal (RH)
(3) Brake Pedal Interlock
(A) "LOCK" (B) "UNLOCK"
S76o518a
1. Interlock both left and right pedals as
showninthegurebeforeoperating
the tractor on the road or engaging
the parking brake.
2. The brake (One side) is used at low
minimum speed. Disengage the
brake pedals and depress the one
side brake pedal only. (Applicable
foreldoperationonly)
3. When the brake pedals are used in
the interlocked mode, adjust them
so that they are depressed to the
same level.
To avoid personal injury:
The tractor may go off the route
or overturn when the brake
(One side) is depressed when
operating at high speed.
•
WARNING
LX500_en_om_05.indd 13 2012-11-27 오후 3:07:33
