Kioti NX4510 User Manual

6
6
3-POINT HITCH IMPLEMENT AND LOADER OPERATION
REMOVAL AND INSTALLATION OF 3-POINT
HITCH IMPLEMENT (WITH PTO SHAFT) .............. 6-2
OPERATION TIP FOR 3-POINT HITCH ELEMENTS ..
6-5
ADJUSTMENT OF LIFT ROD .....................................................6-5
ADJUSTMENT OF TOP LINK ....................................................
6-6
PRECAUTION FOR INSTALLING HOW TO USE
TOP LINK HOLES ..................................................................
6-6
ADJUSTMENT OF STABILIZER .................................................
6-7
DRAFT HITCH AND TRAILER ....................................................
6-8
INSTALLING PTO SHAFT ...........................................................
6-9
HANDLING LOADER ................................................ 6-11
FIXATION POINTS FOR FRONT END LOADER .....................6-12
DRIVING ON SLOPE ................................................................
6-13
JOYSTICK LEVER ....................................................................
6-14
JOYSTICK VALVE .....................................................................
6-17
TE120(NX4510,5010,5510)CABIN,ROP1 1 2014-03-27 오후 3:22:21

Kioti NX4510 Specifications

General

Engine Type	Diesel
Engine Power	45 hp
PTO Power	37.5 hp
Hydraulic System Type	Open center
Drive	4WD
PTO Speed	540 rpm
Ground Clearance	13.4 inches
3-Point Hitch Category	Category I
Displacement	111.4 cu in
