Kioti NX5510 User Manual

6
6
3-POINT HITCH IMPLEMENT AND LOADER OPERATION
REMOVAL AND INSTALLATION OF 3-POINT
HITCH IMPLEMENT (WITH PTO SHAFT) .............. 6-2
OPERATION TIP FOR 3-POINT HITCH ELEMENTS ..
6-5
ADJUSTMENT OF LIFT ROD .....................................................6-5
ADJUSTMENT OF TOP LINK ....................................................
6-6
PRECAUTION FOR INSTALLING HOW TO USE
TOP LINK HOLES ..................................................................
6-6
ADJUSTMENT OF STABILIZER .................................................
6-7
DRAFT HITCH AND TRAILER ....................................................
6-8
INSTALLING PTO SHAFT ...........................................................
6-9
HANDLING LOADER ................................................ 6-11
FIXATION POINTS FOR FRONT END LOADER .....................6-12
DRIVING ON SLOPE ................................................................
6-13
JOYSTICK LEVER ....................................................................
6-14
JOYSTICK VALVE .....................................................................
6-17
TE120(NX4510,5010,5510)CABIN,ROP1 1 2014-03-27 오후 3:22:21

Kioti NX5510 Specifications

General

Fuel Capacity	13.2 gallons
Rated Speed	2, 600 rpm
Brakes	Wet Disc
Hydraulics Type	Open Center
PTO Speed	540 rpm
Transmission	HST or Synchro Shuttle
Steering	Power steering
3-Point Hitch Category	Category I
PTO	Independent
Operating Weight (ROPS Model)	3, 527 lbs (1, 600 kg)
3-Point Hitch	Category I
Engine Type	Diesel
