KIP 2300 - Rear View

Chapter 1 Before Use 1-9
1. 4. 2 Rear view
No. Name Function
1 Rear Counter Rollers Help to transport the original when ejected.
2 USB Terminal USB cable is connected.
- Connected to the PC
- Type B Connector
- 3.3V max
3 HIL Terminal HIL Connector is connected.
- Connected to the PC
- 3.3V max
4 Inlet Power cord is connected.
