Chapter 2 Basic Operation 2-10
2. 2. 2 Scanning a board type original
An original thicker than 1.5mm needs to be scanned in the board original mode, and it also needs
to be fed into the Lower Original Feeder.
Board type original
(1.5 through 16.0mm)
Lower Original Feeder
1. Confirm the Lower Original Feeder Indicator is lighting in green, which means the scanner is
currently acceptable of original.
Lower Original Feeder Indicator
To Next Page
