Chapter 1 Before Use 1-11
1. 5. 2 Specifications for the scan original
Original’s thickness which KIP2300 scanner accepts is 0.05 through 16mm. Originals are divided
into 2 types such as sheet type and board type in terms of the thickness.
- Sheet type : 0.05 through 1.49mm
- Board type : 1.50 through 16.0mm
Sheet type original Board type original
(0.05 through 1.49mm) (1.50 through 16mm)
The available original size differs according to the type.
Sheet type Board type
Length 210 through 16000mm 210 through 1219mm
Width 210 through 1066.8mm 210 through 914mm
Weight - 2.2kg / square meter
Do not scan the following types of original as it may damage the original or scanner itself.
With stick-on label
Torn
Paste
