Chapter 2 Basic Operation 2-4
2. 2 Scanning an Original
2. 2. 1 Scanning a sheet type original
A sheet type original can be fed from both upper and lower original feeders.
- Upper original feeder accepts 0.05 to 0.1mm in thickness.
- Lower original feeder accepts 0.05 to 1.5mm in thickness.
Upper Original Feeder
Sheet type original
(0.05 through 1.0mm)
Lower Original Feeder
(1) Using the Upper Original Feeder
The thickness of original that the upper original feeder can accept is from 0.05 to 0.1mm.
1. Confirm the Upper Original Feeder Indicator is lighting in green. The original can be accepted
only when it is lighting in green.
Upper Original Feeder Indicator
To Next Page
