Chapter 3 Troubleshooting 3-2
3. 1 Original Misfeed
When the original is mis-fed during scanning, remove it manually as instructed in below.
3. 1 When feeding into upper original feeder
1. Open the document upper cover with holding both sides.
Document upper cover
Hold here when opening the document upper cover.
2. Pull up both blue levers to open the scanner upper unit.
Blue levers
To Next Page
