Chapter 1 Before Use 1-5
1. 4 Specifications
1. 4. 1 Printer part
Sub
ect Specification
Model KIP 800 Series
- KIP 850 : 2 rolls digital color and B&W printer
- KIP 860 : 2 rolls digital color and B&W MFP (single footprint)
- KIP 870 : 4 rolls digital color and B&W printer
- KIP 880 : 4 rolls digital color and B&W MFP (dual footprint)
Type Console type full color printer
Printing method LED Array Electro Photography
Color CMYK
Photoconductor Organic Photoconductive Drums
Print speed 80mm/sec. (4 A0/E min or 8 A1/D min.) : Color and monochrome
50mm/sec. for heavy medias
Exposure method Multi-Level (9 levels) LED Print Head
Resolution 600dpi x 2400dpi
Print width Maximum : 914mm (36 inches)
Minimum : 279.4mm (11 inches)
Print length Maximum :
Minimum : 210mm (8.5 inches)
NOTE : If the print is longer than the above, KIP does not
guarantee image quality or the reliability of media feeding
system.
Plain Paper / Bond 5x standard portrait 6000mm in case of A0/36"
Tracing Paper / Vellum 1x standard portrait
Film 1x standard portrait
Glossy Paper 1x standard portrait
Warm up time Shorter than 6 minutes
(At 23 degrees centigrade, 60% RH and 230V)
First print time Shorter than 35 seconds (A1 landscape)
(receiving of data through the completion of ejection from back exit)
Fusing method Dual roller, pressure
Development Contact type mono component non-magnetic development system
Drum charging Corona
Primary & Secondary
Transfer
Transfer rollers
Separation Electrostatic separation (AC)
Media feeding method Automatic (4 or 2 rolls) and manual bypass
Input power 220 to 240V (+6% to -10%), 20A and 50/60Hz
Interface Ethernet 10BASE-T, 100 BASE –TX, 1000 BASE-T
USB 2.0
Power consumption 230V, 50/60Hz
Printing 1.9 Kwh (Average)
Warm up 3.4 Kwh (Average)
Ready 0.8 Kwh (Average)
Cold Sleep 3 W
Avera
e
Acoustic noise Less than 65db (Printing)
NOTE : Impact noise is excluded.
Less than 60db (Ready)
NOTE: The maximum sound pressure level according to EN ISO 7779
is 70 dB or less .
To Next Page
