Kipor IG3000E - Specifications

23
10. SPECIFICATIONS
Model
IG3000E
Type
Inverter
Rated Voltage
120
Frequency
60 HZ
Maximum Output
3000W, 25A
Rated Output
2800W, 23.3A
DC Output
12V-5.0A
Engine Model
KG205GEXi
Engine Type
4 stroke, overhead valve, single cylinder
Displacement
12.0 cu in (196 cc)
Compression Ratio
8.5:1
Engine Speed
3600 rpm with smart throttle off
Cooling System
Forced Air
Ignition System
Transistorized
Oil Capacity
0.57 qt (0.6L)
Fuel Tank Capacity
2.3 gal (9.4 L)
Rated Load Run Time
5 hrs.
Noise Level: no load-full load @ 23' (7m)
68-78 dB
Spark Plug
WR7DC
Length
20 in (491 mm)
Width
17 in (410 mm)
Height
18.5 in (430 mm)
Weight
88 lbs (40 kg)
Spark Plug Gap
0.024-0.028 in (0.6-0.7 mm)
Valve Clearance- cold (Intake)
0.0039 ±.0008 in (0.10 ± 0.02 mm)
Valve Clearance- cold (Exhaust)
0.0059 ± .0008 in (0.10 ± 0.02 mm)
