46
● Inner diameter of cylinder
Standard （mm）
Service limit (mm)
88.015~88.035 88.17
● External diameter of the apron of piston
Standard （mm）
Service limit (mm)
87.96-87.98 87.85
10mm
● Clearance between piston and cylinder
Standard （mm）
Service limit (mm)
0.045~0.065 0.120
● Side clearance of piston
Standard （mm）
Service limit (mm)
0.045~0.060 0.150
