48
● Internal diameter of piston pin hole
Standard （mm）
Service limit (mm)
20.002~20.008 20.050
● Clearance between piston pin and pin hole
Standard （mm）
Service limit (mm)
0.002~0.014 0.080
● Internal diameter of the small terminal of connecting rod
Standard （mm）
Service limit (mm)
20.007~20.020 20.090
● Internal diameter of the large terminal of connecting rod
Standard （mm）
Service limit (mm)
36.015~36.025 36.090
