Kipor KM2V80 User Manual

23
Valve pipe/ Exhaust valve
φ6H7(
+0.012
0
)／φ6
-0.035
-0.050
0.035～0.062
24
Cylinder cover pipe hole/
Valve pipe
φ10H7(
+0.015
0
)／φ10
+0.055
+0.045
-0.03～-0.055
25
Cylinder cover housing washer hole/
Inlet valve housing washer
φ33.5H7(
+0.025
0
)／φ33.5
+0.12
+0.09
-0.065～-0.012
26
Cylinder cover housing washer hole/
Exhaust valve housing washer
φ28H7(
+0.021
0
)／φ28
+0.11
+0.09
-0.069～-0.11
27
Cylinder cover insert/
Combustion chamber insert
φ32.5H7(
+0.021
0
)／32.5p6(
+0.042
+0.026
)
-0.005～-0.042
28
Cylinder cover rocker shaft hole/
Rocker shaft diameter
φ12H7(
+0.018
0
)／φ12f6(
-0.016
-0.027
)
0.016～0.045
29
Rocker arm hole/
Rocker shaft diameter
φ12H7(
+0.018
0
)／φ12f6(
-0.016
-0.027
)
0.016～0.045
30
Timing gear hole/
Camshaft journal
φ24H7(
+0.021
0
)／φ25s6(
+0.048
+0.035
)
-0.014～-0.048
31
Crankshaft gear hole/
Crankshaft journal
φ50H6(
+0.016
0
)／φ50p5(
+0.037
+0.026
)
-0.010～-0.037
32
Flywheel gear ring hole/
Flywheel stop ring
φ214H7(
+0.046
0
)／φ214u7(
+0.364
+0.258
)
-0.212～-0.304
33
Connection rod small head hole/
Connection rod bushing outer
diameter
φ22H7(
+0.013
0
)／φ22r6(
+0.041
+0.028
)
-0.015～-0.041
34
Connection rod bolt hole/
Bolt location diameter
φ7.5H7(
+0.015
0
)／φ7.5f6(
-0.013
-0.022
)
0.013～0.037
35
Side cover outer rotor diameter/
Outer rotor diameter
φ41H7(
+0.025
0
)／φ41
-0.075
-0.115
0.075～0.14
36
Side cover oil pump shaft diameter/
Shaft diameter
φ11H7(
+0.018
0
)／φ11f6(
-0.016
-0.027
)
0.016～0.045
37
Inner/outer rotor hole depth/
Inner/outer rotor axial depth
12
+0.08
+0.04
／12
0 -
0.020
0.04～0.10
