Starting System
1. Starter motor
1.1Check starter motor Refer to Fig 57
（1）Remove the motor excitation & armature winding outlet line from starter motor C wiring
terminal
（2）Connecting the motor case to battery anode with conducting wire.
（3）When connecting the motor case to battery cathode with conducting wire, the motor should
revolve, if not, please check the two windings of the motor.
