USINGTHEBELTLIFTER(cont)
TousetheBeltLifter,youmustfirstraisetheHeadlight
Hood
o
21 . ➤
FlipouttheL-shapedhandleontheBeltLifter
o
20 . Use
ittoturntheBeltLifterfullytotheleft(counter-clock-
wise) until it stops and the red arrows line up. This
stretches the belt and lifts it off the motor shaft. Return the
L-shapedhandleontheBeltLiftertoitsclosedposition.
If you are using your Ultimate G as a straight suction cleaner,
simplylowertheHeadlightHood.TheBrushRollisnow
disengaged and will not rotate when the power switch is
turned ON. ➤
The belt will be stretched to the top of the nozzle as shown.
Tore-engagethebeltsotheBrushRollrotates,simply
raisetheHeadlightHoodandusetheL-shapedhandleto
turntheBeltLifterfullytotheright(clockwise)untilthe
greenarrowslineup.ThenlowertheHeadlightHood.
TheBrushRollwillnowrotatewhenthePowerSwitchis
turned ON.
NOTE: The belt should not be stretched when stored for an
extended period. Make sure the green arrows line up for
storage. ❏
Your Ultimate GisequippedwithaBrushRoll
Performance Indicator Light
o
7 , located on the top
right side of the Power Nozzle. The purpose of this
lightistoshowiftheBrushRollisrotatingproperly.
IftheBrushRollIndicatorLightflashesintermittentlyor
doesnotcomeonwhenusingthePowerNozzle,theBrush
RollBeltmaynotbeworkingproperly.EithertheBeltisnot
engaged or may need to be replaced.
ToreplacetheBrushRollBelt,alsocalledthePowerNozzle
Belt,seePage46.
Getting Started
Getting Started
The Belt Lifter (continued)
1
2
3
4
5

Kirby Ultimate G Series Specifications

General

Type	Upright
Power Source	Corded Electric
Filtration	HEPA
Weight	23 lbs
Bagless	No
Attachments	Crevice tool, upholstery tool, dusting brush
Features	LED headlight
Warranty	3 years
