Kirby Ultimate G Series User Manual

24
The Kirby Company
THEPORTABLESPRAYER
ThePortableSprayerisusedonlyintheBlowerMode.Itis
an excellent tool to apply many different types of water-based
liquids to any type of surface. The spray can be adjusted
ranging from very fine to coarse.
PORTABLESPRAYERSET-UP
UnscrewthejarfromthePortableSprayerandfill3/4
fullwithnon-flammableliquid.Beforereinstallingthe
jar, make sure the portable sprayer dip tube is attached
to the spray gun body. ➤
Screw the jar tightly on the Portable Sprayer and attach
thePortableSprayertotheendoftheAttachmentHose
intheBlowerMode(seepage21).
Make certain your Ultimate GissetupasaBlowerUnit.
TheAttachmentHoseshouldbeconnectedtotheAirExhaust
Port
o
19 . ❏
USINGTHEPORTABLESPRAYER
HoldingthePortableSprayerhorizontally,aimit
toward a sheet of newspaper. Turn the Ultimate G ON
and squeeze the Portable Sprayer trigger, spraying your
non-flammable solution onto the newspaper to check
spray pattern.
NOTE: If the Portable Sprayer must be tilted during usage,
less solution should be used in the jar. This will help avoid
large droplets in the spray. ➤
WARNING:
Never use oil or solvent base paint of any kind in the Portable Sprayer. The
motor is open to the spray and could ignite flammable and volatile solvents.
!
CanisterCleaner&Attachments
CanisterCleaner&Attachments
The Portable Sprayer (Blower Mode Only)
1
2
1

Kirby Ultimate G Series Specifications

General

Type	Upright
Power Source	Corded Electric
Filtration	HEPA
Weight	23 lbs
Bagless	No
Attachments	Crevice tool, upholstery tool, dusting brush
Features	LED headlight
Warranty	3 years
