Kirby Ultimate G Series User Manual

30
The Kirby Company
CARPETSHAMPOOSYSTEMSET-UP
Vacuum thoroughly before shampooing for maximum clean-
ing.Then,removetheOuterPermanentBag
o
1 and the
Power Nozzle
o
25 to prepare for shampooing.
ByusingtheL-shapedhandle,turntheCarpet
ShampooSystemNozzleBeltLiftertotheright(clock-
wise) until the green arrows line up. ➤
Slide the slots on the side of the Carpet Shampoo
System Nozzle over the outer shoulders of the Carpet
Shampoo System Tray. ➤
While pushing up on the belt with your finger, use
theL-shapedhandleontheBeltLiftertoturnitleft
(counter-clockwise looking at it from the front) until
theredarrowslineup.(TheBeltLifterHookwillcatchand
stretch the belt.) ➤
Press the Toe-Touch Control
TM
BottomPedal
o
9 all
the way down to raise the front of the Ultimate G. ➤
Optional Accessories
Optional Accessories
The Carpet Shampoo System
2
1
3
4

Kirby Ultimate G Series Specifications

General

Type	Upright
Power Source	Corded Electric
Filtration	HEPA
Weight	23 lbs
Bagless	No
Attachments	Crevice tool, upholstery tool, dusting brush
Features	LED headlight
Warranty	3 years
