Kirby Ultimate G Series User Manual

14
The Kirby Company
Upright&PortableCleaner
Upright&PortableCleaner
The Upright Cleaner/Straight Suction Upright Cleaner
If power assist is desired, engage TechDrive
®
by push-
ing down the yellow “D” side (marked “D” for Drive) of
theTechDrivePowerAssistN/DPedal
o
12 located just
below the Power Switch
o
13 . ➤
To turn your Ultimate G OFF, press the Toe-Touch
Control
™
BottomPedal
o
9 all the way down until noz-
zle is fully raised.
Disengage TechDrive by stepping on the gray “N” side
(marked“N”forNeutral)oftheTechDrivePowerAssistN/D
Pedal
o
11 .
Turn the Ultimate G OFF by pressing the Power Switch
o
13
and then unplugging. ❏
STRAIGHTSUCTIONCLEANER
Straight Suction Cleaning allows you to vacuum hard floors,
throwrugsanddelicatecarpetswithoutuseoftheBrushRoll.
NOTE: When using Straight Suction Cleaning without the
HardFloorPad,eitheroncarpetsorbarefloors,lowerthe
nozzle as close as possible to the floor without scraping it.
With the Ultimate GturnedOFF,raisetheHeadlight
Hood
o
21 . ➤
FlipouttheL-shapedhandleontheBeltLifter
o
20 .
UseittoturntheBeltLifterallthewaytotheleft
(counter-clockwise) until the red arrows line up (see
page10).ReturntheL-shapedhandleontheBeltLifterto
its closed position.
ThenlowertheHeadlightHood.
TheBrushRollisnowdisengagedandyourUltimate G will
operate as a Straight Suction Cleaner. ❏
5
4
1
2

Kirby Ultimate G Series Specifications

General

Type	Upright
Power Source	Corded Electric
Filtration	HEPA
Weight	23 lbs
Bagless	No
Attachments	Crevice tool, upholstery tool, dusting brush
Features	LED headlight
Warranty	3 years
