22
The Kirby Company
BLOWERSET-UP(cont)
RaisetheHeadlightHood
o
21 and flip out the L-shaped
handleontheBeltLifter
o
20.UseittoturntheBelt
Lifter all the way to the left (counter-clockwise) until
the red arrows line up.
Unlock the Power Nozzle
o
25 by turning the Accessory
Lock
o
22 all the way to the left (counter-clockwise). The
Power Nozzle should tip forward when it is released.
Lift nozzle away from the Ultimate G and off.
When using the blower attachments, the Air Intake
Guard must be attached to the front of the Ultimate G.
FastentheAirIntakeGuardontotheAttachingBar
o
24
thesamewayyouwouldtheAttachmentHose.Thenlockit
on by turning the Accessory Lock
o
22 all the way to the right
(clockwise).
ToremovetheentireBagAssembly,grasptheMini
Em-Tor
®
o
6 in the hand-hold provided and rotate it out
and away from the Ultimate G as far as it will go. Then
lift it off.
(ToreplacetheBagAssemblyafteruseasablower,seepage10.)
ReleasetheOuterPermanentBagTopfromtheBagSupport
o
16bypressingtheBagReleaseButton
o
16 and sliding the
bag top down. (See page 15 for details.)
CanisterCleaner&Attachments
CanisterCleaner&Attachments
Using your Ultimate G as a Blower (continued)
2
3
4
5
