Kirisun DM588 User Manual

DM588 Service Manual
SN
Material Code
Specifications
QTY
25 7MBS-4304-03B-W M50 speaker clamping ring 1
26 7MBR-4291-02A-W3 DM588 waterproof ring of panel 1
27
4SS7-3520-016-700
Speaker
1
28
7MBR-4304-04A-W0
M50 speaker seal ring
1
29
7SMF-025050M-MHYB-B
R M2.5*5 torx mushroom-head machine screw
1
30
7SMF-025050M-MHYB-B
R M2.5*5 torx mushroom-head machine screw
4
31
7NRC-040050204-LJ
M2.0*5+4 hexagon copper post
2
32 7MBS-4291-02A-W DM588 PCB grounding shrapnel 2
33 2RW3-RE1101CA1-H01-3 Volume switch 1
34 7MBS-4304-04B-W M50 metal dome array 1
35 6SS2-4291-HKB DM588 front key board nesting 1
36 7MBR-4304-06A-W0 M50 keys (P+R) 1
37 7MBB-4304-01A-W0 M50 speaker dust screen 1
38
7MHR-4002-16B-W9
Waterproofing gasket of DP770 knob, ultra-thick
2
39
7SMF-025050M-MHYB-B
R M2.5*5 torx mushroom-head machine screw
2
40
7MHS-1767-02B-W
PT6800 knob circlip
1
41 7MBR-4304-02B-W3 M50 alarm key 1
42 7NRC-077107040-Z R encoder switch nut 1
43 7MBP-4304-03A-W0 M50 volume knob 1
7. Debugging
After replacing a component, it may be necessary to detect and adjust technical indexes of the radio.
7.1.Debugging Devices
(1) Antenna interface converter
(2) Test wires
18

Kirisun DM588 Specifications

General

Brand	Kirisun
Model	DM588
Category	Radio
Language	English
