DM588 Service Manual
Appendix 3 Material List (Structural Part)
1 0SS3-MK4291-BMA Front-housing assembly material Front-housing assembly material 1
2 6SS3-MK4291-BMA Front-housing assembly Front-housing assembly, lead free 1
3 7MBP-4291-01B-W0 Plastic front housing
ABS, black, 7 hot-melt copper nuts, ultrasonically processed
decorative stripes, Xiangtong brand
1
4 7MBP-4304-08C-WC Glass (for model M50)
PMMA, transparent, 42.0*35.0*1.5, laser cutting, Xinzhiding
brand
1
5 7MBR-4304-02B-W3 Alarm key (for model M50)
High-elasticity silicon rubber, hardness 60°, PT orange 21C,
screen print PT 169C, Mingkun brand
1
6 7MBR-4304-03A-WC Light pipe (for model M50)
High-elasticity silicon rubber, hardness 70°, milky white,
1
7 7MBR-4304-06A-W0 Function key (for model M50) Material: P+R, black, oil jet, laser etching, Mingkun brand 1
8 7MBB-4304-01A-W0 Dust screen for speaker (for model M50)
Nylon net, black, with single-sided adhesive and PET gasket,
thick 0.4mm, Xinlongda brand
1
Volume knob (for model M50)
ABS (757#), black, etched, Xiangtong brand
10 7MBR-4304-04A-W0 Seal ring for speaker (for model M50)
High-elasticity silicon rubber, black, hardness 40°, Mingkun
brand
1
11 7MBR-4304-05A-W0A Rubber plug for SIM card (for model M50)
High-elasticity silicon rubber, black, hardness 60°, adhered to
stainless plate, Mingkun brand
1
12 7MBS-4304-01A-W LOGO plate (for model M50)
0.5mm, stainless steel SUS304#, polished, oblique
1
13 7MBS-4304-02A-W LCD holder (for model M50) 0.4mm, stainless steel SUS304#, original color, Junyu brand 1
14 7MBS-4304-03B-W Clamping ring for speaker (for model M50)
0.8mm, stainless steel SUS301#, original color, modified
1
15 7MBS-4304-04B-W Metal dome array (for model M50)
SUS301+PET, φ5*3.7 kidney-shaped 5-spot metal dome
array, ten points, IP67, larger sound hole
1
93
