DM588 Service Manual
SN
Material NO
Material Name
Specifications
QTY
surface resistance < 1 Ohm/cm, lead free
31 7MBR-4291-04A-W0 Waterproof cover for speaker socket
High-elasticity silicon rubber, black, hardness 60±5°, Xindahui
brand, lead free
1
32 7MBR-4291-05A-W0 Antenna plug
Silicon rubber, black, hardness 60±5°, Xindahui brand, lead
free
2
33 7MBR-4062-08A-W0 Waterproof pad for power socket High-elasticity silicon rubber, black, Mingkun brand, lead free 1
34 7MBR-4062-11A-W0 Waterproof ring for GPS antenna connector
High-elasticity silicon rubber, hardness 40°, black, Mingkun,
lead free
1
35
3CR7-S1943-D
PT8200 antenna connector
Phosphor copper, MOT-50KY interface, lead free
1
36 6SS2-4324-HK1A Nesting for tube power amplifier RD35 RD35 nesting 1
37 6SS1-4324-HK1A Nesting for tube power amplifier RD35 RD35 nesting 1
38 0SS1-4324-HK1A SMD material for tube power amplifier RD35 SMD material 1
39 7MBC-4291-01A-W Cooling fins for power amplifier Pure copper, 1mm thick, lead free 1
40 1TF1-RD35HUP235W High-power RF LDMOS
Mitsubishi, RD35HUP2, VHF/UHF (135-560MHz) vdd=12.5V
35W
1
41 3WF7-05050-070D4 FPC cable
Spacing 0.5mm, 50P, length 70mm, 3mm long terminal,
stiffener 4mm, dual connectors, single-face, reverse
1
42
7MHR-7069-08A-W0
O-shaped ring
D2.4X1.0MM, Xincheng brand, lead free
10
43 7SMF-025050M-MHYB-B R M2.5*5 torx mushroom-head machine screw
558/PT558/4200/PT4200/PT558S (preferred), harden iron,
Φ2.5mm*5mm, electrophoresis, nylok
2
44 7SMF-030060M-SZYB-N
R M3*6 cross recessed mushroom-head
machine screw
8000/PT8000/PT8200/DR550/DM580 (preferred), harden
iron, Φ3mm*6mm, nickel plated, metric coarse thread
7
45 7SMF-030160M-MHYB M3*16 torx round-head machine screw
Stainless steel, Φ3mm*16mm, passivated, metric coarse
thread, lead free
8
46 7SAF-030080M-SZYB-Z1
R M3*8 cross recessed mushroom-head
combined machine screw
KME215/620/PT8000/82008100 (limited), harden iron,
Φ3mm*8mm, electrophoresis, flat washer, lead free
5
47 7MBR-4291-06A-W0
Thermal conductive pad for audio power
amplifier
Thermal conductive silicon rubber, 0.5mm thick, Xinlongda
brand, lead free
1
48 7GGS-090043008-W Flat washer Washer GB/T97.1 4 A2, stainless steel, inner diameter 1
95
