DP405 Digital Two-way Radio User Manual
7
No.
Part Name
1
Antenna
2
PTT key
Press this key to initiate a call and talk
3
Side key (programmable key)
This key can be set with different features by dealer. Please refer to “5 Programmable Keys”
for further details
4
Speaker
Voice Output.
5
Channel Knob
Rotate the knob to select channel 1-16.
6
Power/Volume Knob
Turn it clockwise to turn on the radio. For turning off the radio, turn it counter-clockwise until
a click is heard.
When the radio is on, rotate the knob to adjust the volume.
7
LED Indicator
Red indicator means the radio is transmitting, green means receiving and when the red
indicator flashes, it means power shortage.
8
Microphone
Voice input
9
External port
Open the cover plate and connect the external speaker and microphone
10
Belt Clip
11
Battery Latch
