5 Set-up, installation and connection
5.1 Setting up the unit
When setting up the unit, observe the following set-up conditions:
n Select a dry and well ventilated set-up location.
n Do not set up the unit next to heat sources.
n Avoid direct sunlight.
n Set up the unit on a firm, level surface.
n Compensate for uneven ground with adjustable feet.
n Do not cover, block or line the ventilation grille.
n Do not cover, block or line the cooling machine.
n Maintain a minimum distance of 2 cm between wall and unit
(for example by means of a spacer).
n Maintain a minimum distance of 2 cm between units.
5.2 Installing the unit
BL-100 BL-100-eco
Have the unit installed only by staff qualified for the task. If in
doubt, contact KIRSCH
Ä
“Manufacturer’s address” on page 4.
Install the unit as shown in the installation drawing provided.
5.3 Connecting the unit
The unit is designed according to protection class I
and protection type IP 20 and is ready to be
plugged in.
Ensure the connection conditions specified in the technical data
and on the type plate.
1. Check the connecting cable of the power plug for damage.
2. Plug in power plug.
Set-up
Overview of units suitable for
installation
Installing
Connecting
Set-up, installation and connection
Connecting the unit
18.12.2018 Refrigerator/freezer BL series 39
