WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on
our products by anyone other than authorized In-Home Service Professionals.
FORWARD
This KitchenAid Job Aid “27˝ & 30˝ Electric Built-In Single Oven” (Part No. 4317418), provides the
In-Home Service Professional with information on the installation, operation, and service of the
27˝ & 30˝ Electric Built-In Single Oven. For specic information on the model being serviced, refer
to the “Use and Care Guide,” or “Tech Sheet” provided with the oven.
The Wiring Diagram and Strip Circuits used in this Job Aid are typical and should be used for
training purposes only. Always use the Wiring Diagram supplied with the product when servicing
the oven.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide information that will enable the In-Home Service Professional
to properly diagnose malfunctions and repair the 27˝ & 30˝ Electric Built-In Single Oven.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose malfunctions.
• Successfully perform necessary repairs.
• Successfully return the oven to its proper operational status.
Copyright © 2007, Whirlpool Corporation, Benton Harbor, MI 49022
