4-22
REMOVING OVEN DOOR GASKET
1. Remove the oven door (see the procedure
on page 4-20).
2. Remove the screw from the door gasket
retainer and remove the retainer.
3. Pull the door gasket clips out of the oven
liner holes and remove the gasket.
Gasket Retainer Screw
Gasket Clip
Door Gasket
To Next Page
