KITO ER010S - Page 20

Remarks：(1) Description for inner spacers
For example, 0＋1
0：the number of spacers on the left side of the shaft
1：the number of spacers on the right side of the shaft
(2) Adjustment of trolley width
Refer to (b) of 5.2 on the next page.
Adjust the dimensions by appropriately increasing or decreasing the
number of inner or outer adjusting spacers, without strictly adhering to
the number of adjusting spacers shown in the above table.
(3) Spacer arrangement example
Table 5-2 Adjusting spacer arrangement for Low Head Suspension
