Manual Trolley TS2 (TSG/TSP) Periodic Inspection
■
Check result :
○
Good,
△
To be replaced (adjusted) next inspection,
×
Bad, Needs replacement (adjustment)
Category
Check item Check method Criteria
Inspection date/result
/ / / / / /
Body size component
Wheel
Visual inspection/
inspection by
measurement
• To have no apparent deformation and damage
• Abrasion of outer diameter to be less than limit
value
Lifting shaft
Visual inspection/
inspection by
measurement
• To have no apparent deformation and damage
• Abrasion of outer diameter to be less than limit
value
Suspender
Visual inspection/
inspection by
measurement
• To have no apparent deformation and damage
• Abrasion of outer diameter to be less than limit
value
Travel rail
Rail surface Visual inspection
• To have no attachment of paint, oil and foreign
matter
• To have no dust and powder due to abrasion
Deformation, abrasion
Visual inspection/
inspection by
measurement
• To have no deformation of beam ange such as
twist and shear drop
• To have no exceeding abrasion of rail surface
Rail xing bolt Visual inspection
To be mounted securely without looseness and
come-off
Stopper Visual inspection
To be mounted securely without looseness and
come-off at the rail end
Function/performance
Operational check
Traveling
operation with a
capacity
Visual inspection/
inspection by
measurement
Perform inspection of the items on function/
performance of daily inspection with no load, and
then perform the inspection of the same items with
a capacity.
Strange noise
Traveling
operation with a
capacity
Visual inspection/
inspection by
measurement
Perform inspection of the items on function/
performance of daily inspection with no load, and
then perform the inspection of the same items with
a capacity.
• When any abnormality is observed during inspection, stop the
use of electric chain hoist, indicate “FAILURE”, and contact the
maintenance engineer or KITO for repair.
Use of the product with abnormality may result in death or serious injury.
Mandatory
Decide the check items
appropriate to the
environment and operating
conditions of the customer.
NOTE
Executed by Inspector
Checked by Maintenance Engineer
A
Check Sheet for ER2 Series Electric Chain Hoist Periodic Inspection
DANGER
To Next Page
