STEP 1: Plug the servos into the Servo:Lite board.
The board connections are:
STEP 2: With both wheel servos plugged in, it is time to write some test
code. Set out the servos like below. This will allow trimming/calibration of
the servos. This means they will stop and travel at the same speed when
commanded.
BOARD
LOCATION
WHAT IT
DOES
WIRE
COLOUR
TOP GROUND BROWN
MIDDLE POWER RED
BOTTOM SIGNAL ORANGE
