ASSEMBLING THE SERVO:LITE PCB
STEP 1: Use a small Phillips screwdriver to screw the five M3 machine
screws through the micro:bit and spacer into the nuts mounted on the PCB.
ZIP LEDs
Servo Connections
PCB Mounted Nuts
On/Off Switch
Spacer
Micro:bit sold separately
