Kiturami K1-22E - Control Panel LCD

12
ۣૐ ۞ইૐ઺Ҵૐ ೠҴ࢑সӏѺ ಿ૕҃৔మ
LCDhasabacklightthatwillilluminate:
•Whenauseractionisdetected(abuttonispressed).
•Thetimeoutisapproximately20seconds.
3.4 Control Panel LCD
S1
S21
S23
S2 S3 S4 S5 S6 S36
S7
S37
S39
S22
S24
S28
S35
S38
S29 S30 S32 S33
S31
1 2 3 4
S15~19
S8~14
Segment Name Description
Testmode Testmodeindication
Anti-freezemode Anti-freezemodeindication
Storage Heating mode
StoredWaterBeingHeated,canbe
adjusted
Lockmode Buttons-lockedmodeicon
Communication Communication icon
CH mode CentralHeatmodeiconcanbeadjusted
Outsidetemp Operatingbyoutsidetemperature
DHW mode CombinationboilerSetPoint,canbeadjusted
StatusandInstallermode
TheStatusModeortheInstallerModeisActive
(allparameters)
Flamesignal Flame Signal icon
Pumpicon Water pump operation (CH or DHW) icon
