ۣૐ ۞ইૐ઺Ҵૐ ೠҴ࢑সӏѺ ಿ૕҃৔మ
Therearetwodifferenttypesofterminals(horizontaland
vertical),forboththecoaxialremovalsystemandthedual
ductremovalsystem.
Carefullystudythediagramsrepresentingthedifferenttypes
ofremovalandselecttheonethatbestsuitstheconditionsof
yourinstallation.
Tochoosetheremovalaccessoriesrequiredforeach
installation,seethelistofaccessoriesontheKITURAMI
Accessorieslistprovidedfromourofcialagencies.
Types
PipeDiameter
(mm)
Orientation
Maximum
Length(m)
Coaxial
Flue
Ø60/Ø100
Horizontal 20
Vertical 20
Twin
Flue
Ø80/Ø80
Horizontal 21
Vertical 21
-MaximumFlueLength
5.6 Unpacking
Beforeinstallation,checkalltheitemsthatreferredtopage6
“IncludedAccessoriesList”.
Auesystemforrearorsidecanbesuppliedasaseparate
orderorbuyitintheaftermarket.
1)
2)
3)
▪MaximumTotalLength
Thetotallengthofthetubesmustnotexceedthemaximum
valuedefined.Iftheremovalinstallationincludeselbows
whilecalculatingthetotallengthyoumusttakeintoaccount
thateachelbowhasaresistanceequaltoaspeciclinear
Leqequivalentlength(seetable).
Types
PipeDiameter
(mm)
Elbow
Equivalent
Length(m)
Coaxial
Flue
Ø60/Ø100
45º 1.0
90º 1.5
Twin
Flue
Ø80/Ø80
45º 0.5
90º 2.0
-EquivalentLengthofElbows
