7.3 GasConversion
■TheK1condensinggasboilerisconguredforNaturalGas
(NG)fromthefactory.
■IfyourgassupplyisPropaneGas(LP),yourboilercanbe
convertedtoburnpropanegasasfollows:
1.TurnOFFtheBoiler.TheON/OFFbuttonislocatedatthe
bottomleftoftheControlDisplay.
2.TurnOFFtheGASandWATERsupplytotheBoiler.
(valvesarelocatedontheplumbingpipes.)
3.UsingaPhillipsscrewdriver,removethe4screwsonthefront
cover.
4.LocatetheGasInletPipeatthetopleftoftheunitasisshown
inFigurebelow,andloosentheBrassFittingsatbothendsof
theGasInletPipe.
5.Completelyun-threadtheBrassFittingontheright,andthen
carefullyswingtheGasInletPipedownwardjustenoughsothat
itisoutoftheway.
6.RemovetheexistingNaturalGasorice.Savethepacking
forre-use.
7.ReplacetheoldOricewiththenewOriceforLP(propane)
gas.Re-usethepackingfromprevious.
8.ReturntheGasInletPipetoitsoriginalpositionandtighten
bothoftheBrassFittings.
9.SetthemaincontrollerDipSwitchtochangethegastype.
10.TurnONtheGASandWATERsupplytotheBoiler.
11.Aftercompletingconversion,applythesticker,present
intheconversionkit,nearthedata-plate.Usinganindelible
markerpen,cancelthedatarelativetotheoldtype.
Aftermakingsurethatconversionwascarriedoutwithanozzle
ofsuitablediameterforthetypeofgasusedandthesettings
aremadeatthecorrectpressure,checkthattheburnerame
isnottoohighorlowandisstable(doesnotdetachfrom
burner).
Packing
Nozzle
Power
(Kcal)
SwitchPosition
1 2 3
16,000 - ON -
20,000 ON ON -
25,000 - - ON
30,000 ON - ON
Power
(Kcal)
SwitchPosition
5 6
G20 - -
G21 ON -
G30 - ON
G31 ON ON
Table1
Table2
DipSwitch
7.3.1NaturalGastoPropaneConversion
