Kiturami K1-22E - Horizontal Coaxial Flue Fitting

24
ۣૐ ۞ইૐ઺Ҵૐ ೠҴ࢑সӏѺ ಿ૕҃৔మ
CAUTION
SUPPORT-Alluesystemmustbesecurelysupportedata
MINIMUMofonceeverymeter&everychangeofdirection.
Itisrecommendedthateverystraightpieceissupported
irrespectiveoflength.Additionalsupportsareavailableas
accessories.
▪Theboilerhasbeenpositionedonthewall,ttheueseal
intotheinternalueturret.
▪Fittheelbowintothetopoftheboilerandrotatetothe
requiredposition.Itispossibletorotatetheelbow360°onits
verticalaxis.
▪Usingtheueclamp,sealsandscrewssuppliedsecurethe
elbowtotheboiler.
▪The1meterhorizontaluekitsuppliedissuitableforanexact
generallydimensionof850mm.
▪Measurethedistancefromthefaceoftheexternalwalltothe
faceoftheueelbow,thismustnowbesubtractedfrom850
mm,nowhavethetotalamounttobecutfromtheplainend
oftheue.
5.5.8FittingtheCoaxialFlue(Ø60/Ø100-HorizontalFlueSystem)
1)ConcentricBend
2) Concentric Terminal
3)InternalWallSealingPlate
4)ExternalWallSealingPlate
▪Cuttheuetotherequiredlengthtakingcarenottocut
theinnerue,nextcuttheinnerueensuringthatthelength
betweentheinnerandouterueismaintained.
▪Ifttingtheuefrominsideofthebuildingattachtheouter
wallsealtotheueterminalandpushtheuethroughhole,
oncethewallsealhaspassedthroughthehole,pulltheue
backuntilthesealisushwiththewall.
▪Shouldtheuerequireextending,theueconnectionsare
pusht,however,
oneuebracketshouldbeusedtosecureeachmeterofue.
▪Anyadditional“inline”bendsintheuesystemmustbe
takenintoconsideration.
▪Theirequivalentlengthsare:
-ConcentricPipes:45°bend1.0meters/90°bend1.5meters
•Installtheconnectingpipewithaminimumfallof3°towards
theboiler.
•Maximumpermissibleequivalentuelengthsarebelow
example.
- C
13
HorizontalFlueSystem
1
2
4
- Calculation C
13
FlueLength
Max.Length=A+B(1X90ºelbow)=20-1.5=18.5M
3
B
A
