2-3-7 Installing flue (Fitting The Flue (Cont) )
A Directly below an opening, air brick, opening widow, etc.
B Above an opening, air brick, opening window etc
C Horizontally to an opening, air brick, opening window etc
D Below gutters, soil pipes or drain pipes
E Below eaves
F Below balconies or car port roof
G From a vertical drain pipe or soil pipe
H From an internal or external corner
I Above ground, roof or balcony level
J From a surface or boundary line facing a terminal
K
From a terminal facing a terminal (Vertical flue).
L From an opening in carport (e.g. door, window) into the dwelling
M Vertically from a terminal on the same wall
N Horizontally from a terminal on the same wall
R From adjacent wall to flue (vertical only).
S
T Adjacent to windows or openings on pitched and flat roofs
U Below windows or openings on pitched roofs
NOTE; the flue must not be installed in a place likely to cause a nuisance and positioned to ensure that
Nproducts of combustion do not discharge across a boundary.
