Kiturami WORLD PLUS-13D - 5 ) Maintenance Guide; Main Heat Exchanger

5. MAINTENCE GUIDE
1. Unplug 1. Disassemble connector,main controller,
2. Lock the gas valve
circulation pump.
3. Loose the clamp under the body and open the 2. With + driver, unscrew the screws under the
front cover.①
body and on the pipes.
3. Loose the nuts between pipes and heat
exchanger and separate the heat exchanger.
1. Separate the base plate from body after unscrewing. 1. With + driver, dismentle the screw fixing the
burner.
2. Separate the heat exchanger.
accident of gas leakage.
2
5-1 Main heat exchangeur
※ On reverse order, assemble the parts and boiler.
1
Tool
Warning ! : Carefully assemble the cover and nut to seal the parts. If fail to seal, there may occur the
1
2
3
4
5
6
잠 김 풀 림
27페이지
