1. With spanner, loose the nuts of gas valve 1. Separate the heat exchanger from the burner after
and pipes. unscrewing.
2. By unscrewing the screws of gas valve in 2. Unscrew in the base plate and take off the burner from
the base plate, separate the gas valve. the base plate.
Warning ! : Carefully assemble the burner and heat exchanger with silicons to seal. If fail to seal, it may
cause the imperfect combustion.
Tool
5-2 Burner unit
1
