Fixing the camera to a bike
1. Unscrew both screws (i) and place both halves (ii) of the
Bicycle Mount (A) around the desired position on the bike.
2. Replace the screws (i) and tighten them until the mount is
rmlyinplace.
3. Remove the screw from the top of the Mount (iii) and slot the
camera (inside waterproof case) into position, replace screw
and tighten to lock in position.
4. If you wish to use a forward-facing bar you may wish to use
the 90° adaptor (iv) in between the camera and the bicycle
mount to make the camera forward-facing.
(iii)
(iv)
(ii)
(i)
