Fixing the camera to a vented helmet
1. Fix the camera to the Mount Clip (i).
2. Threadthesuppliedstrapsthroughtheslotsinaatorcurved
AdhesiveMount(don’tremovetheadhesivelm)(ii).
3. Attach the camera assembly to the strap mount assembly by
sliding it in until it clicks into position.
4. Afterxingthecameratothemountcorrectly,usethestrapto
xittothehelmet.Adjustthelengthaccordingtothehelmet’s
size, and then push the clips down into position to lock the
straps in place.
(i)
(ii)
