89
EN
Step 6: Install Drain Hose
1 Connect the drain hose to the drain line of the indoor air conditioner.
2 Wrap adhesive tape around the connecting piece.
Note: Wrap insulating material around the drain hose to prevent condensation. The
plastic plugs are not included.
Step 7: Cable Connection of the Indoor Air Conditioner
1 Open the panel, remove the screw on the wiring cover and then take down the
cover.
Outlet pipe
Drain hose
Drain hose
Outlet
pipe
Insulation material
Tape
Drain hose
Panel
Screw
Wiring cover
To Next Page
