ENGLISH
SYMBOLS USED ON LCD
~
AC Measurement DC Measurement
-
Negative DC Value
AUTO
Auto Range Active
Low Battery
A
Current in Amps
H
Hold Active Diode Test
V
Voltage Measurement Continuity Test
Hz
Frequency in Hertz
%
Duty Cycle
F
Capacitance in Farads
°
F
Temperature in Fahrenheit
Ω
Resistance in Ohms
M
Mega 10
6
m
Milli 10
-3
k
Kilo 10
3
n
Nano 10
-9
μ
Micro 10
-6
• Display shows resistance.
• Buzzer sounds if less than 60Ω
Continuity Features:
HOLD
4. Temperature: -4°
≤
°F
≤
1832°
Features:
HOLD
• Use included thermocouple.
AUTO
A
AC
AUTO
A
AC
AUTO
A
AC
AUTO
A
AC
PRESS
TO SELECT
Diode
Resistance
Capacitance
Continuity
A
AC
• F
<
100μF
• Wait up to 60 seconds for measurement.
•
Safely discharge capacitor before
measurement.
Capacitance Features:
HOLD RANGE
Display shows:
• Forward voltage drop if forward biased.
• “O.L.” if reverse biased.
Diode Features:
HOLD
• Ω < 40MΩ
•
Do not measure resistance
on a live circuit.
Resistance Features:
HOLD RANGE
5. Resistance / Capacitance / Diode / Continuity
ELECTRICAL SPECIFICATIONS
DC Voltage Measurement
Range Resolution Accuracy
400mV 0.1mV
± (0.8% + 2 digits)
4V 0.001V
40V 0.01V
400V 0.1V
600V 1V ± (1.0% + 2 digits)
Overload Protection: 600V DC / AC
Input Impedance: 10MΩ.
AC Voltage Measurement
Range Resolution Accuracy
400mV 0.1mV
± (1.0% + 10 digits)
4V 0.001V
40V 0.01V
400V 0.1V
600V 1V ± (1.2% + 10 digits)
Overload Protection: 600V DC / AC
Frequency: 40 to 400Hz
Input Impedance: 10MΩ.
Response: Averaging
AC Current Measurement
Range Resolution Accuracy
4A 0.001A ± (3.5% + 20 digits)
≤
0.5A
4A 0.001A ± (3.0% + 10 digits)
>
0.5A
40A 0.01A ± (3.0% + 10 digits)
400A 0.1A ± (2.5% + 10 digits)
600A 1A ± (1.5% + 5 digits)
Overload Protection: 720A for 60 sec. max
Frequency: 50 to 60Hz
Response: Averaging
Resistance Measurement
Range Resolution Accuracy
400Ω 0.1Ω
± (1.2% + 2 digits)
4kΩ 0.001kΩ
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ
40MΩ 0.01MΩ ± (2.0% + 5 digits)
Overload Protection: 600V DC / AC
