Klein Tools CL800 User Manual

3
ELECTRICAL SPECIFICATIONS
Function Range Resolution Accuracy (50/60 Hz)
AC Voltage
(V AC)
6.000V 1mV ±(1.5% + 5 digits)
60.00V 10mV
±(1.2% + 5 digits)
600.0V 100mV
1000V 1V ±(1.5% + 5 digits)
DC Voltage
(V DC)
600mV 0.1mV ±(1.0% + 8 digits)
6.000V 1mV
±(1.0% + 3 digits)60.00V 10mV
600.0V 100mV
1000V 1V ±(1.2% + 3 digits)
Input Impedance: 10MΩ Frequency Range: 50 to 400Hz
Maximum Input: 1000V AC RMS or 1000V DC
AC Current
(A AC)
60.00A 10mA ±(2.0% + 8 digits)
600.0A 100mA ±(2.0% + 5 digits)
DC Current
(A DC)
60.00A 10mA ±(2.0% + 8 digits)
600.0A 100mA ±(2.0% + 5 digits)
Frequency Range: 50 to 60Hz
Function Range Resolution Accuracy
Resistance
600.0Ω 0.1Ω
±(1.5% + 5 digits)
6.000kΩ 1Ω
60.00kΩ 10Ω
600.0kΩ 100Ω
6.000MΩ 1kΩ
60.00MΩ 10kΩ ±(2.0% + 10 digits)
Maximum Input: 600V AC RMS or 600V DC
Capacitance
60.00nF 0.010nF ±(5.0% + 35 digits)
600.0nF 0.1nF
±(3.0% + 5 digits)6.000µF 0.001µF
60.00µF 0.01µF
600.0µF 0.1µF
±(5.0% + 5 digits)
6000µF 1µF
Maximum Input: 600V AC RMS or 600V DC
Temperature
(Fahrenheit)
-14° to 32°F
0.1 to 1 °F
±(2.0% + 9 °F )
33° to 752°F ±(1.0% + 5.4 °F )
753° to 1000°F ±(2.0% + 9 °F )
Temperature
(Celsius)
-26° to 0°C
0.1 to 1 °C
±(2.0% + 5 °C )
1° to 400°C
±(1.0% + 3 °C )
401° to 538°C
±(2.0% + 5 °C )

Klein Tools CL800 Specifications

General

Category	Clamp Meter
True RMS	Yes
Resistance	60MΩ
Continuity	Yes
Diode Test	Yes
Inrush Current	Yes
Backlit Display	Yes
Operating Altitude	6562 ft (2000 m)
Battery	2 x AAA
Safety Rating	CAT IV 600V, CAT III 1000V
AC Voltage	600 V
DC Voltage	600 V
Capacitance	6000 µF
AC Current	600A
DC Current	600A
Operating Temperature	32° to 122°F (0° to 50°C)
