Klein Tools MM720 User Manual

3
ELECTRICAL SPECIFICATIONS
VOLTAGE (AUTO-RANGING)
Function Range Resolution Accuracy ( 50–60 Hz )
AC Voltage
(V AC)
6.000V 1mV
±(1.0% + 3 digits)60.00V 10mV
600.0V 100mV
1000V 1V
±(1.2% + 5 digits)
DC Voltage
(V DC)
600.0mV 0.1mV
±(0.5% + 5 digits)6.000V 1mV
60.00V 10mV
600.0V 100mV
±(0.8% + 3 digits)
1000V 1V
±(1.0% + 3 digits)
Input Impedance: 10MΩ
Frequency Range: 50 to 400Hz
Maximum Input: 1000V AC RMS or 1000V DC
CURRENT (AUTO-RANGING)
AC Current
(μA and mA)
600.0μA 0.1μA
±(1.0% + 5 digits)
6000μA 1μA
60.00mA 10μA
600.0mA 100μA
6.000A 1mA
±(2.0% + 3 digits)
10.00A 0.01A
±(2.0% + 5 digits)
DC Current
(μA and mA)
600.0μA 0.1μA
±(1.0% + 3 digits)
6000μA 1μA
60.00mA 10μA
600.0mA 100μA
6.000A 1mA
±(1.5% + 3 digits)
10.00A 0.01A
Overload Protection: 800mA/1000V and 10A/1000V fuses
Frequency Range: 50 to 400Hz
Maximum Input: µA/mA setting: 600mA AC RMS / DC
10A setting: 10A AC RMS / DC
RESISTANCE (AUTO-RANGING)
Function Resolution Accuracy
600.0Ω 0.1Ω
±(1.2% + 5 digits)
6.000kΩ 1Ω
60.00kΩ 10Ω
600.0kΩ 100Ω
6.000MΩ 1kΩ
60.00MΩ 10kΩ
±(2.0% + 10 digits)
Maximum Input: 600V DC or 600V AC RMS
