Page #8 background imageLoading...
Page #8 background image
8
FUNCTION BUTTONS
ON/OFF
To Power ON the meter rotate the Function Selector switch
2
from
the OFF setting to any measurement setting. To Power OFF the meter
rotate the Function Selector switch
2
to the OFF setting. By default
the meter will automatically Power OFF after 5 minutes of inactivity.
Reactivate meter by pressing any button. To deactivate the automatic
Power OFF feature, power the meter ON with the SEL button
11
depressed. When automatic Power OFF is deactivated, the
symbol will not be visible in the display.
When the Function Selector switch is rotated to a measurement
setting, "LEAD" flashes on the display as a reminder to check that test
leads are inserted into the appropriate jacks.
"SEL" (SELECT) BUTTON (FOR SECONDARY FUNCTIONS)
The "SEL" button
11
activates the secondary functions for each
setting accessible by the Function Selector switch
2
. For Current,
Voltage and Low Z, it toggles between AC and DC. For the other
functions, it switches between Continuity, Resistance, Diode-test,
and Capacitance. The default function for each application is printed
on the meter in white; the secondary functions are printed on the
meter in orange.
"HOLD" (DATA HOLD) / BACKLIGHT BUTTON
Press HOLD
10
to hold the measurement on the display. Press
again to release the display to return to live measuring.
Press and hold the "HOLD" button
10
for more than one second
second to manually adjust the backlight. Meter default is automatic
control of backlight based upon an optical sensor. The long presses
will scroll between high backlight, low backlight, and back to
automatic control. In automatic backlight mode, the "A" and
icons will be displayed. For manual backlight mode, the "M" and
icons will be displayed
"RANGE" BUTTON
The meter defaults to auto-ranging measurement mode . This
automatically determines the most appropriate measurement range
for the testing that is being conducted. To manually force the meter
to measure in a different range, use the "RANGE" button
7
.
1. Press the "RANGE" button
7
to manually select measurement
range ( is deactivated on the LCD). Repeatedly press
the "RANGE" button
7
to cycle through the available ranges,
stopping once the desired range is reached.
2. To return to auto-ranging mode, press and hold the "RANGE"
button
7
for more than one second ( is reactivated).
ENGLISH
