9
FUNCTION BUTTONS
"REL" (RELATIVE) BUTTON
Relative measurements are available for Voltage, Current,
Resistance, Temperature, Capacitance and LoZ.
1. Perform first measurement.
2. With test leads connected, press REL
8
to set frame of reference.
3. Perform second measurement. The value displayed is the
difference between first and second measurements.
"MAX/MIN" BUTTON
When the "MAX/MIN" button
9
is pressed, the meter keeps track
of the minimum and maximum value of the measurement as the
meter continues to take samples.
1. When measuring, press MAX/MIN
9
and the meter displays the
maximum value. If a new maximum occurs, the display updates
with that new value. Pressing again reveals the minimum value.
If a new minimum occurs, the display updates with the new
value.
2. Press MAX/MIN
9
and hold for more than one second to return
to normal measuring mode.
